0.5mm thickness perforated metal plate stainless steel perforated
Product Description
China Wind Dust Wall Perforated Sheet Wind Protection Net, Hot Sale Windproof Dust Suppression Mesh, Windproof Dust Suppression
Hole Pattern
round, square, hexagonal, scale, rectangular, triangle, cross, slotted.
Surface Treatment of stainless steel perforated plate
*Galvanized: Galvanized including hot-dip galvanized and electic galvanized.
*PE/PVC coated,white,green,blue,red,yellow etc
ROUND HOLES STAGGERED PATTERN | |||
HOLE | CENTERS | GAUGE / PLATE THICK. | OPEN AREA |
.020" RD | .045" Stag | 26 | 18% |
1/32" RD | 1/16" Stag | 22 | 23% |
3/64" RD | 5/64" Stag | 24 | 33% |
1/16" RD | 3/32"Stag | 22 thru 16 | 40% |
5/64" RD | 1/8" Stag | 22 thru 14 | 35% |
3/32" RD | 5/32" Stag | 24 thru 14 | 33% |
.117 RD | 5/32" Stag | 18 | 51% |
1/8" RD | 3/16" Stag | 24 thru 11 | 40% |
9/64" RD | 3/16" Stag | 18 | 51% |
5/32" RD | 3/16" Stag | 22 thru 16 | 63% |
3/16" RD | 7/32" Stag | 22 thru 16 | 67% |
1/4" RD | 5/16" Stag | 20 thru 16 | 58% |
17/64" RD | 5/16" Stag | 20 | 66% |
5/16"RD | 7/16" Stag | 20 thru 1/4" | 46% |
3/8" RD | 9/16" Stag | 20 thru 1/4" | 40% |
1/2" RD | 11/16" Stag | 20 thru 1/4" | 48% |
5/8" RD | 7/8" Stag | 10 thru 1/4" | 46% |
3/4" RD | 1" Stag | 16 thru 1/4" | 51% |
1" RD | 1-3/8" Stag | 10 thru 1/4" | 48% |
Other specifications parameter size support customization |
